I  Product overview

◆Category: This product is one/two-component baking paint with high-grade resin as film material;

◆Constitution: High-grade resin, pigment, packing material, addictives, water, etc.;

◆Characteristics:

※Water is the disperse medium of this product, nonflammable and nonexplosive at normal temperature;

※Fine adhesion, weatherability, protection and decoration performance;

※No poisonous or toxic substances produced in the course of construction and film formation, environmental friendly and according with the instruction RoHs of European Union.



II   Scope of application: apply for surface coating of household glass and ceramics.



III  Technical data (typical data)





Item	Indicator
Color and appearance	Thick liquid of different color
Fineness	≤20μm
PH value	8.0~9.0
Viscosity (paint-4cup)	≥30s
Solid content (120°C /2 hour)	≥32% (true color)
Gloss (60° photometer)	0~90
Adhesion (Grid method)	≤5% paint off
Pencil hardness	≥3H
Resistivity against water (dip in tap water at normal temperature)	No blistering, peeling, or discoloration in 7 days
Resistance to essences (point contact)	No blistering, peeling, or discoloration in 10h
Alcohol resistance (95% absolute alcohol)	No peeling with grid method after dipping for 12h
Wine resistance (alcoholic strength: 52% vol wine)	No peeling with grid method after dipping for 24h

(Note: test conditions for resistance to water, alcohol, wine and essences: 1. Substrate: wipe cleaned glass plate with alcohol; 2. Coating: spray coating, dry film 15μm~20μm; 3. Drying: 180±2°C, baking at constant temperature for 30min.)



IV  Construction for reference

◆Surface treatment: wipe off the impurity, for example, floating dust, oil stain, etc. to keep the surface clean and dry;

◆Form of construction work: spray coating;

◆Thinner: purified water or clean tap water;

◆Dilution ratio: add water by 5%~10% of the paint weight, or adjust as the case may be;

◆Applicable viscosity: immersion 25~30s (paint-4cup, 23±2°C);

◆Type of drying: bake at a constant temperature of 180±2°C for 30 min;

◆Coating thickness: 10μm ~20μm (dry film thickness, single layer).



VII  Attentions

◆Difference in the level of processing substrate is referred to final effect and barrier property of the film coating;

◆After coating, let work pieces sit in dustless environment for 5~10min before accessing baking equipment;

◆Keep the product in a cool and ventilate place (0°C~45°C). The validity is half a year. If failing to meet the time limit, the product still can be used if proved to be up to standard through inspection.



VI  Packing and shipping

◆Packing: 20kg/barrel or 50kg/barrel;

◆Shipping: transport as non-hazardous goods.
